NMAX 125 TECH CRYSTAL GRAPHITE

Descrição

Engine

• Engine Type
• 4-stroke, Liquid-cooled, SOHC, 4-valves
• Displacement
• 125cc
• Bore x Stroke
• 52 × 58.7mm
• Compression Ratio
• 11.2 : 1
• Maximum Power
• 9kW (12.2PS) @ 8,000rpm
• Maximum Torque
• 11.2Nm (1.1 kg-m) @ 6,000rpm
• Starter System
• Electric
• Transmission
• V-Belt Automatic
• Lubrication System
• Wet sump
• Clutch Type
• Ignition System
• TCI
• Final Transmission
• Fuel Consumption
• 2.2l/100km
• CO2 Emissions
• 52g/km
• Fuel System
• Fuel Injection

DIMENSIONS

Oil Tank Capacity

Fuel Tank Capacity

7.1l

Length (mm)

1,935mm

Width (mm)

740mm

Height (mm)

1,200mm

Wheel Base (mm)

1,340mm

Weight (kg)

132kg

Ground Clearance (mm)

125mm

FRAME

Front Tyre

110/70-13M/C 48P Tubeless

Rear Tyre

130/70-13M/C 63P Tubeless

Frame

Caster Angle

Trail

Front Suspension System

Telescopic forks

Rear Suspension System

Unit Swing

Front Travel

100mm

Rear Travel

91mm

Front Brake

Hydraulic single disc brake

Rear Brake

Hydraulic single disc brake
